Or Rent From $113.24 per week
Return any time after minimum rental agreement. Learn More
Specifications
Weight 15.7 kg
Dimensions 118.9 × 40.1 × 11.9 cm
Manuals
Upper 73 notes (61 playing keys plus 12 Preset Keys), Square-front (“waterfall”-style), New mechanical key-bed design.
SPLIT
SPLIT panel control, Assignable split point
Tone Generator
MTW™ (Modeled Tone Wheels), 61-note polyphony for Manuals, 5-note polyphony for Pedals
Virtual Multi-Contacts™
Custom Contacts (3 Factory, 3 User), 3 Physical Contacts, 9 Assignable Virtual Contacts, Adjustable Attack, Release, Decay
Harmonic Drawbars®
5 sets (4 Manuals, 1 Pedal), Upper 2 X 9 pitches, Lower 2 X 9 pitches, Pedal 2 pitches
Drawbar Voicing
4 choices for Manuals (A-100, B-3, C-3, Mellow), 4 choices for Pedals (Normal, Muted, Synth 1 & 2)
Custom Tone Wheel (CTW™)
3 Factory, 3 User for A-100, B-3, C3 & Mellow Drawbar Voicings, CTW’s identified by model and serial number, Adjustable parameters for each tone wheel, 12 complex tone wheels for bottom, 12 pedal tones
Touch-Response Percussion™
Percussion On, Normal/Soft Volume, Slow/Fast Decay, 2nd & 3rd Harmonic, Adjustable Normal/Soft Volume
settings, Slow/Fast Decay rates, Velocity, Key Tracking, 1’ Drawbar Cancel ON/OFF
Vibrato & Chorus™
Virtual Scanner™ (3 settings), Adjustable rate, Vibrato/Chorus Mix, Vibrato on Pedal ON/OFF
Overdrive
Tube/Solid State, Adjustable drive level
Preset Keys
9 Presets plus Cancel each Manual, 2 Adjust Presets each Manual, 9 programmable Preset Banks
Patches
100 User, 100 Factory Patches
Assignable to Preset Keys as
Favorites
Assignable Patch Load: Drawbar
registrations, Drawbar parameters,
Internal & External Zones, MultiEffects, Reverb
Tube Preamp
12AU7/12AX7 Tubes
Adjustable Routing & Drive Level
MT™ Matching Transformer
Adjustable drive level, Hysteresis,
upper/lower/percussion levels
Multi-Effects
Tremolo, Auto Pan, Wah-Wah, Ring
Modulator, Phaser, Flanger, Chorus,
Delay. Adjustable parameters for
each effect.
Master Equalizer
Bass/Mid/Treble panel controls
Adjustable gain & center frequency
Programmable Equalizer
Bass, Mid, Treble
Adjustable center frequency
Hammond Preamp Tone Control
Leslie®
STOP, FAST, BYPASS panel controls.
Custom Cabinets (8 Preset, 8 User)
Adjustable Slow & Fast Speeds, Rise
& Fall Times, Horn/Drum/Subwoofer
Volume Balance, Microphone
Settings
Reverb
ON/OFF panel control
11 programs
Leslie On Reverb ON/OFF
MIDI
5 MIDI Templates
3 Keyboard Channels (Upper, Lower,
Pedals)
6 External Zones (3 Upper, 2 Lower,
1 Pedals)
Assignable MIDI channels, key
range, Program Change, Pan,
Velocity Curve, Min/Max Volume
IN 1, IN 2, OUT Connections
Display
OLED, 20 character, 2 line
7 Control Buttons & VALUE Rotary
Knob
USB
“A” port (“To USB Flash Drive”)
“B” port (“To Host”)
Tune/Transpose
Transpose +- 6 semitones
Fine Tune +- 10 cents
Octave Up/Down +- 2 octaves
H-BUS Connector
To Pedals/Expression Pedal
Audio Connections
LINE OUT L/MONO / R, Headphone Jack, 11-pin Leslie® Connector
Other Connections
CONTROL 1, CONTROL 2,
8-pin DIN (EXP-100F Expression
Pedal)
AC Input
